Denon AVR-X7200W Service Manual

NO
NO
NO
Is U6503 (TOP267EG) damaged?
Are there the damage in U6503 and
D6503 / C6506?
Repair the short circuited area by the
soldering of the PCB.
Check the damage of each part.
Replace the damaged part.
Replace the damaged part.
Has a fuse (F70) broken?
Are there any short circuits caused by
the soldering of the PCB?
Are any parts damaged?
Replace the U6503 (TOP267EG) and
D6503.
DC 5V is not output.
YES
YES
YES
YES
YES
YES
6. SMPS
115

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
