ENGLISH
6
Getting started
Basic connections Basic operation Specifications IndexAdvanced connections Advanced operations TroubleshootingExplanation of terms
Connections for all compatible audio signal formats are described
in this owner’s manual. Please select the type of connections
corresponding to the equipment you are connecting.
NOTE
• Do not plug in the power cord until all connections have been
completed.
• When making connections, also refer to the owner’s manual of the
other components.
• Be sure to connect the left and right channels properly (left with
left, right with right).
• Do not bundle power cords together with connection cables.
Doing so can result in humming or noise.
• Do not connect the unit to the PHONO input connectors on the
amplifier.
Preparations
Connecting cables
Select the cables according to the equipment being connected.
Audio cables
Analog connections (stereo)
R
L
R
L
Audio cable (supplied)
(White)
(Red)
Basic connections
Analog connections
R
L
R
L
AUDIO
RL
IN
AUDIO
Amplifier
Connecting the power cord
To household power outlet
(AC 230 V, 50 Hz)
Power cord
(included)
NOTE
• Insert the plugs securely. Loose connections will result in the
generation of noise.
• Do not unplug the power cord while the unit is operating.
Basic connections
1.DCD1510AEE2_ENG_009.indd 6 2010/02/24 8:20:55
