Revision1.0 DN-C635 Serial Interface Specification
Date 2003-01-28 22 page of 39
2.6.10 Request Program Table command
This command acquires 10 occurrences of information that is registered to program with unit.
1) Command format
byte/bit 7 6 5 4 3 2 1 0
0 STX( 0x02 )
1 Command code (‘;’)
2 Program Table Num (‘0’ – ‘9’) (Table 47)
3 Reserve ( 0x00 )
4 Reserve ( 0x00 )
5 Reserve ( 0x00 )
6 ETX( 0x03 )
7 BCCH( high-level )
8 BCCL( low-level )
Table 46. Request Program Table command
CODE Program / Direct Status
0x30 (‘0’) Program Num 01 – 10
0x31 (‘1’) Program Num 11 – 20
0x32 (‘2’) Program Num 21 – 30
0x33 (‘3’) Program Num 31 – 40
0x34 (‘4’) Program Num 41 – 50
0x35 (‘5’) Program Num 51 – 60
0x36 (‘6’) Program Num 61 – 70
0x37 (‘7’) Program Num 71 – 80
0x38 (‘8’) Program Num 81 – 90
0x39 (‘9’) Program Num 91 – 99
Table 47. Program / Direct answer
2) Answer format
byte/bit 7 6 5 4 3 2 1 0
0 STX( 0x02 )
1 Reply code (‘;’)
2 Answer code (Table 3)
3 Program Table Num (‘0’ – ‘9’) (Table 47)
4 Program Num 1 Track number 100 digits
5 Program Num 1 Track number 10 digits
6 Program Num 1 Track number 1 digits
7 Program Num 2 Track number 100 digits
8 Program Num 2 Track number 10 digits
9 Program Num 2 Track number 1 digits
10 Program Num 3 Track number 100 digits
11 Program Num 3 Track number 10 digits
12 Program Num 3 Track number 1 digits
13 Program Num 4 Track number 100 digits
14 Program Num 4 Track number 10 digits
15 Program Num 4 Track number 1 digits
16 Program Num 5 Track number 100 digits
17 Program Num 5 Track number 10 digits
18 Program Num 5 Track number 1 digits
19 Program Num 6 Track number 100 digits
To Next Page
