Revision1.0 DN-C635 Serial Interface Specification
Date 2003-01-28 31 page of 39
2.6.18 Program / Direct command
This command Selects a program mode or a direct mode.
1) Command format
byte/bit 7 6 5 4 3 2 1 0
0 STX( 0x02 )
1 Command code (‘G’)
2 Program / Direct Code
(Direct : ‘0’, Program : ‘1’, Program input : ‘2’, Program input end: ‘3’)
3 Reserve ( 0x00 )
4 Reserve ( 0x00 )
5 Reserve ( 0x00 )
6 ETX( 0x03 )
7 BCCH( high-level )
8 BCCL( low-level )
Table 64. Program / Direct command
2) Answer format
byte/bit 7 6 5 4 3 2 1 0
0 STX( 0x02 )
1 Reply code (‘G’)
2 Answer code (Table 3)
3 ETX( 0x03 )
4 BCCH( high-level )
5 BCCL( low-level )
Table 65. Program / Direct answer
3) Special condition
This command receives it only when it stops.
