32
DN-S1000
PARTS LIST OF P.W.B. UNIT
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model E2: Europe model
JP: Japan model
GU-3607 MAIN P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 262 3044 001 MN102H730F
IC102 00D GEN 6696 SYSTEM ROM SUB ASS'Y 8M FLASH MEMORY(70N)
IC103 00D 263 1034 906 PST600H-T
IC104 00D 262 1953 903 TC7WU04F +C
IC105 00D 262 3305 902 SN74LV393APW
IC106 00D 262 3166 905 PCM1748E(TAPE) +C
IC108 00D 262 2518 907 SN74LV74APW-EL2 +C
IC109 00D 262 2517 908 SN74LV08APW-EL2 +REF
IC110 00D 263 1079 903 BA033FP +C
IC201 00D 262 3398 003 MN6627933
IC202 00D 262 3159 909 AN8785SB
IC203 00D 262 3160 901 AN22002A
IC207 00D 263 0615 902 BA15218F-DXE2 +C
IC210 00D 262 3401 000 64M SDRAM(TSOP)
IC401 00D 262 3399 002 ADSP-BF531(LQFP)
IC402 00D 262 3407 004 128M SDRAM(TSOP)PBF
IC403,404 00D 262 2640 901 SN74LV245APW-EL2
IC405 00D 262 2959 906 SN74LV244APW +REF
IC406 00D 262 2640 901 SN74LV245APW-EL2
IC408 00D 262 2518 907 SN74LV74APW-EL2 +C
IC409 00D 262 2516 909 SN74LV32APW-EL2 +C
IC410 00D 262 3400 904 TPC6103
IC411 00D 262 2948 904 SN74LV86APW +REF
TR101 00D 269 0082 902 DTC114EKT96 +C
TR201 00D 272 0125 904 2SB709A +C
TR202,203 00D 269 0082 902 DTC114EKT96 +C
D101 00D 276 0559 909 DAP202KT146 +C
D401 00D 276 0559 909 DAP202KT146 +C
D402 00D 276 0750 902 RB521S-30TE61 +REF
LD101 00D 393 9633 008 SELU1250CM(RED)
RESISTORS GROUP
R205 00D 244 2043 937 RS14B3A100JNBST(S)
CAPACITORS GROUP
C101 00D 257 0512 903 CK73F1E104ZT +1608
C102 00D 254 4533 918 CE04W0J470MT SMG/RE3
C103-107 00D 257 0512 903 CK73F1E104ZT +1608
C108 00D 254 4533 918 CE04W0J470MT SMG/RE3
C109 00D 254 4300 947 CE04W0J470MT(SRE)
C110-113 00D 257 0512 903 CK73F1E104ZT +1608
