DN-S1000
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model E2: Europe model
JP: Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
1 00DGU-3607 MAIN PWB UNIT ASS'Y 1
2 00DGU-3608 PANEL PWB UNIT ASS'Y for E3 1
2 00DGU-36082 PANEL PWB UNIT ASS'Y for E2 1
2 00DGU-3608J PANEL PWB UNIT ASS'Y for JP 1
2-1 PANEL UNIT
2-2 SLIDE VR UNIT
2-3 DISC SENSOR UNIT
2-4 DISC SWITCH UNIT
2-5 POWER UNIT
3 00D 411 2057 206 CHASSIS 1
4 00D 146 2302 002 P.SW KNOB GUIDE 1
5 00D 412 2741 010 P.W.B.HOLDER (H=6) 1
6 00D 415 0935 005 PROTECT SHEET 1
7 00D 412 2814 044 CARD SPACER (L=6) 3
8 00D 412 5188 007 SPRING PLATE 1
9 00D 445 0084 009 CORD BUSH for E3 1
9 00D 445 0056 008 CORD BUSH for E2,JP 1
10 00D 337 0128 004 CD MECHA (CD11-02) 1
11 00D 443 1585 103 DISC DUIDE 1
12 00D 415 0936 004 BLIND SHEET 1
13 00D 415 0937 003 FIX PLATE 1
14 00D 412 5104 007 MAIN PWB BRACKET 1
15 00D 103 1807 307 TOP COVER ASS'Y 1
16 00D 425 0251 003 TOP COVER BEARING 1
17 00D 146 2365 007 FADER PLATE 1
18 00D 146 2366 006 JOG RING 1
19 00D 463 0960 008 SPRING PLATE 1
20 00D 422 0671 105 DISC SHAFT 1
21 00D 421 0796 100 WHEEL ASS'Y 1
22 00D 421 0797 015 SCALE DISK 1
23 00D 441 1970 000 DISK FIX PLATE 1
24 00D 443 1573 005 S.COVER (GP1A70R) 1
25 00D 119 0126 000 R.KEY (FUNCTION) 1
26 00D 119 0127 106 R.KEY (PLAY/PAUSE) 1
27 00D 119 0128 008 R.KEY (PITCH) 1
28 00D 421 0822 003 SLIP MAT 1
29 00D 421 0823 109 SCRATCH DISC 1
30 00D 421 0830 008 ADAPTOR ASS'Y 1
31 00D 421 0825 000 DISC HOLDER 1
32 00D 113 1951 014 FADER KNOB 1
33 00D 112 0891 004 KNOB (MARU) 1
34 00D 113 1689 001 P.SW KNOB 1
35 00D 105 1462 007 BOTTOM PLATE 1
36 00D 461 0706 114 FOOT SHEET 4
37 00D 421 0828 007 ANTI-STATIC SHEET 1
38 00D 421 0831 007 SLIP SHEET 1
39 00D 412 5194 004 SHIELD BRACKET 1
! 40 00D 233 6473 008 POWER TRANS T801 1
41 00D 412 5197 001 EARTH BRACKET 1
! 42 00D 206 2155 001 AC CORD W/CON.E3 for E3 1
! 42 00D 206 2089 106 AC CORD W/CON.E2 for E2 1
