Denon PMA-50 User Manual

Source Direct
Set whether to adjust the tone.
Off
(Default):
Adjusting the tone.
On:
Tone is not adjusted. Tone adjustments (Bass,
Treble, Balance) are disabled.
Bass
Adjusts the bass sound.
–8dB – +8dB (Default : 0dB)
Treble
Adjusts the treble sound.
–8dB – +8dB (Default : 0dB)
Balance
Use o p to adjust the left/right volume balance.
H/P AMP Gain
Set the gain of the headphone amplifier. Set this according to the
impedance of the connected headphones. It is recommended that this is
set on the “Low” side if the headphones have low impedance and on the
“High” side if they have high impedance.
Low
(Default):
Set the gain of the headphone amplifier to
“Low”.
Mid:
Set the gain of the headphone amplifier to
“Mid”.
High:
Set the gain of the headphone amplifier to
“High”.
NOTE
The headphone volume varies depending on the “H/P AMP Gain” setting. Decrease
the volume or mute the audio first if changing this setting while listening to audio.
Contents Connections Playback Setting procedure Tips Appendix
47
Front panel Display Rear panel Remote Index

Denon PMA-50 Specifications

General

Amplifier class	-
Audio output channels	- channels
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.004 %
RMS power output per channel (4 Ohm)	50 W
RMS power output per channel (8 Ohm)	30 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	35 W
Purpose	Home
Cooling type	Passive
Product color	Black, Silver
Connectivity technology	Wired & Wireless
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial in	1
Digital audio optical in	2

Weight and Dimensions

Depth	258 mm
Width	200 mm
Height	86 mm
Weight	2500 g
