Denon POA-A1HD Service Manual

13
POA-A1HDCI/POA-A1HD
●修理時の組み立て注意点
1. RADIATOR ASSY
ねじ止めをしていない状態で RADIATORASSY が傾い
ている場合は、ワイヤーを挟んでいないか確認する。
2. TOP COVER
TOPCOVER の止めねじは
00D4719058022SPECIALSCREW(forSP)
00D4719058035SPECIALSCREW(forBK)
b 必ず L=6のねじを使用する。
●Notes for assembly under repair.
1. RADIATOR ASSY
If RADIATOR ASSY inclines without screws.Check the
wire that got caught in the RADIATOR ASSY.
2. TOP COVER
Fasten the screw for TOP COVER.
00D 471 9058 022 SPECIAL SCREW (for SP)
00D 471 9058 035 SPECIAL SCREW (for BK)
bUse the screw (L = 6) without fail.
.
L=6

Denon POA-A1HD Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Audio output channels	9.1 channels
Connectivity technology	Wired
Dimensions (WxDxH)	434 x 530 x 297 mm
