Denon RCD-N7 User Manual

34
ENGLISH
Other functions
Inputting characters
You can change the names as desired using the “Preset Name”
(vpage16), “Napster Account” (vpage 22), “Last.fm account”
(vpage21) and character input for the network functions.
For inputting characters, there are two methods, as shown below.
Method Operations
Using the number
buttons
• Operating with the remote control unit.
• Multiple characters are assigned to
a button, and each time the button is
pressed, a character is switched.
Using the cursor
buttons
• Operating with the remote control unit
or the main unit.
• Use uio p and [ENTER] or <1/3
ENTER>
to input characters.
n Display of an input screen
select move
P03
[Username]
select
: enter
GPreset nameH
GAccount inputH
Cursor
Using the number buttons
1
Display the screen for inputting characters .
2
Place the cursor at the character to be changed with
o p and press [NUMBER] (0 – 9) until the desired
character is displayed.
• The types of characters that can be input are as shown below.
1 . @ - _ / :
˜
m n o M N O 6
a b c A B C 2 p q r s P Q R S 7
d e f D E F 3 t u v T U V 8
g h i G H I 4 w x y z W X Y Z 9
j k l J K L 5
0 (Space) ! “ # $ % & ‘ ( )
z
+ ,
; < = > ? [ \ ] ^ ` { | }
• The input character type can be switched by pressing [MODE]
while the display name is being changed.
• For entering the characters assigned to one number button
continuously, press p to move the cursor to the right after entering
a character then enter the next character.
• For entering characters assigned to separate buttons, press the
number button continuously. The cursor automatically moves to
the next position, and the entered character is registered.
3
Repeat step 2 to change the name then press [ENTER]
or <1/3 ENTER > to register it.
Example:For changing characters from “POPS” to “ROCK”
q Place the cursor at “P”.
POPS
w Press seven times.
ROPS
“P” changes to “R”.
e Press p twice.
ROPS
“R” is automatically registered, and the cursor
placed “P”.
r Press
six times.
ROCS
“P” changes to “C”.
t Press p.
ROCS
“C” is registered and the cursor placed “S”.
y Press
fi ve times.
ROCK
“S” changes to “K”.
u Press
[ENTER] or <1/3 ENTER> to register the input name.
Button located on both the main unit and the remote control
BUTTON
Button only on the main unit <BUTTON>
Button only on the remote control [BUTTON]
Symbols used to indicate buttons in this manual
[NUMBER]
u
p
[ENTER]
i
o
[TUNER]
[CD]
[MODE]
[USB]
[iPod]
ON/STANDBY
[8]
[9]
[1/3]
/&5803,$%3&$&*7&33$%/
<VOLUME df>ON/STANDBY
p i
<1/3 ENTER> o u
<5>
1.RCDN7E2ENG5th0831.indd341.RCDN7E2ENG5th0831.indd34 2010/09/0115:10:042010/09/0115:10:04

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
