2. Select the high speed (2) setting by sliding the
gear shifter (D) back (away from the chuck).
IMPORTANT: Use carbide-tipped or masonry
bits only.
3. Drill with just enough force on the hammer to
keep it from bouncing excessively or “rising” off
the bit. Too much force will cause slower drilling
speeds, overheating and lower drilling rate.
4. Drill straight, keeping the bit at a right angle to
the work. Do not exert side pressure on the bit
when drillling as this will cause clogging of the
bit flutes and a slower drilling speed.
5. When drilling deep holes, if the hammer speed
starts to drop off, pull the bit partially out of the
hole with tool stil running to help clear debris
from the hole.
NOTE: A smooth, even flow of dust from the hole
indicates proper drilling rate.
Screwdriver Operation (Fig. 1, 6)
1. Turn the torque adjustment collar (C) to the
desired position.
2. Select the desired speed/torque range using
the gear shifter (D) to match the speed and
torque of the planned operation.
NOTE: Use the lowest torque setting required
to seat the fastener at the desired depth. The
lower the number, the lower the torque output.
3. Insert the desired fastener accessory into the
chuck as you would any drill bit.
4. Make some practice runs in scrap or on unseen
areas to determine the proper position of the
clutch collar.
5. Always start with lower torque settings, then
advance to higher torque settings to avoid
damage to the workpiece or fastener.
MAINTENANCE
Your DeWALT power tool has been designed to
operate over a long period of time with a minimum
of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular
cleaning.
WARNING: To reduce the risk of
serious personal injury, turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories. An accidental start-up can
cause injury.
The charger and battery pack are not serviceable.
Drill Operation (Fig. 1, 4)
WARNING: To reduce the risk of
personal injury, ALWAYS ensure
workpiece is anchored or clamped firmly.
If drilling thin material, use a wood “back-
up” block to prevent damage to the
material.
1. Turn the collar (Fig. 4, C) to the drill symbol.
2. Select the desired speed/torque range using
the gear shifter (Fig. 1, D) to match the speed
and torque to the planned operation.
3. For WOOD, use twist bits, spade bits, power
auger bits or hole saws. For METAL, use
high-speed steel twist drill bits or hole saws.
Use a cutting lubricant when drilling metals.
The exceptions are cast iron and brass which
should be drilled dry.
4. Always apply pressure in a straight line with the
bit. Use enough pressure to keep drill biting,
but do not push hard enough to stall the motor
or deflect the bit.
5. Hold tool firmly with both hands to control
the twisting action of the drill. If model is not
equipped with side handle, grip drill with one
hand on the handle and one hand on the
battery pack.
CAUTION: Drill may stall if overloaded
causing a sudden twist. Always expect
the stall. Grip the drill firmly to control the
twisting action and avoid injury.
6. IF DRILL STALLS, it is usually because
it is being overloaded or improperly used.
RELEASE TRIGGER IMMEDIATELY, remove
drill bit from work, and determine cause of
stalling. DO NOT CLICK TRIGGER ON AND
OFF IN AN ATTEMPT TO START A STALLED
DRILL — THIS CAN DAMAGE THE DRILL.
7. To minimise stalling or breaking through the
material, reduce pressure on drill and ease the
bit through the last fractional part of the hole.
8. Keep the motor running when pulling the bit
back out of a drilled hole. This will help prevent
jamming.
9. With variable speed drills there is no need to
centre punch the point to be drilled. Use a
slow speed to start the hole and accelerate by
squeezing the trigger harder when the hole is
deep enough to drill without the bit skipping
out.
Hammerdrill Operation (DCD796 only)
(Fig. 1, 5)
1. Turn the collar (C) to the hammerdrill symbol.
english
Should you find one day that your D
eWALT product
needs replacement, or if it is of no further use to
you, do not dispose of it with household waste.
Make this product available for separate collection.
Separate collection of used products
and packaging allows materials to be
recycled and used again. Re-use of
recycled materials helps prevent
environmental pollution and reduces
the demand for raw materials.
Local regulations may provide for separate collection
of electrical products from the household, at
municipal waste sites or by the retailer when you
purchase a new product.
D
eWALT provides a facility for the collection and
recycling of DeWALT products once they have
reached the end of their working life. To take
advantage of this service please return your product
to any authorised repair agent who will collect them
on our behalf.
You can check the location of your nearest
authorised repair agent by contacting your local
D
eWALT office at the address indicated in this
manual. Alternatively, a list of authorised DeWALT
repair agents and full details of our after-sales
service and contacts are available on the Internet at:
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when
it fails to produce sufficient power on jobs which
were easily done before. At the end of its technical
life, discard it with due care for our environment:
• Run the battery pack down completely, then
remove it from the tool.
• Lithium-ion cells are recyclable. Take them to
your dealer or a local recycling station. The
collected battery packs will be recycled or
disposed of properly.
Lubrication
Your power tool requires no additional lubrication.
Cleaning
WARNING: Blow dirt and dust out of
the main housing with dry air as often as
dirt is seen collecting in and around the
air vents. Wear approved eye protection
and approved dust mask when
performing this procedure.
WARNING: Never use solvents or
other harsh chemicals for cleaning the
non-metallic parts of the tool. These
chemicals may weaken the materials
used in these parts. Use a cloth
dampened only with water and mild
soap. Never let any liquid get inside the
tool; never immerse any part of the tool
into a liquid.
CHARGER CLEANING INSTRUCTIONS
WARNING: Shock hazard. Disconnect
the charger from the AC outlet before
cleaning. Dirt and grease may be
removed from the exterior of the charger
using a cloth or soft non-metallic brush.
Do not use water or any cleaning
solutions.
Optional Accessories
WARNING: Since accessories, other
than those offered by DeWALT, have not
been tested with this product, use of
such accessories with this tool could be
hazardous. To reduce the risk of injury,
only DeWALT recommended accessories
should be used with this product.
Consult your dealer for further information on the
appropriate accessories.
Protecting the Environment
Separate collection. This product must
not be disposed of with normal
household waste.
15
