DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially
hazardous situation which, if not avoided,
may result in minor or moderate
injury.
Fuses:
Europe 230V tools 10 Amperes, mains
U.K. & Ireland 230V tools 3 Amperes, in plugs
Definitions: Safety Guidelines
The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.
The vibration emission level given in this information
sheet has been measured in accordance with a
standardised test given in EN60745 and may be
used to compare one tool with another. It may be
used for a preliminary assessment of exposure.
WARNING: The declared vibration
emission level represents the main
applications of the tool. However if the
tool is used for different applications,
with different accessories or poorly
maintained, the vibration emission may
differ. This may significantly increase the
exposure level over the total working
period.
Battery pack DCB180 DCB181 DCB182 DCB183/B DCB184/B DCB185
Battery type Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion
Voltage V
DC
18 18 18 18 18 18
Capacity Ah 3.0 1.5 4.0 2.0 5.0 1.3
Weight kg 0.64 0.35 0.61 0.40/0.45 0.62/0.67 0.35
Charger DCB105
Mains voltage V
AC
230
Battery type 10.8/14.4/18 Li-Ion
Approx. charging time of
battery packs
min
25 (1.3 Ah)
55 (3.0 Ah)
30 (1.5 Ah)
70 (4.0 Ah)
40 (2.0 Ah)
90 (5.0 Ah)
Weight kg 0.49
Charger DCB107 DCB112
Mains voltage V
AC
230 230
Battery type 10.8/14.4/18 Li-Ion 10.8/14.4/18 Li-Ion
Approx. charging time of
battery packs
min 60 (1.3 Ah) 70 (1.5 Ah) 90 (2.0 Ah) 40 (1.3 Ah) 45 (1.5 Ah) 60 (2.0 Ah)
140 (3.0 Ah) 185 (4.0 Ah) 240 (5.0 Ah) 90 (3.0 Ah) 120 (4.0 Ah) 150 (5.0 Ah)
Weight kg 0.29 0.36
Charger DCB113 DCB115
Mains voltage V
AC
230 230
Battery type 10.8/14.4/18 Li-Ion 10.8/14.4/18 Li-Ion
Approx. charging time of
battery packs
min 30 (1.3 Ah) 35 (1.5 Ah) 50 (2.0 Ah) 25 (1.3 Ah) 30 (1.5 Ah) 40 (2.0 Ah)
70 (3.0 Ah) 100 (4.0 Ah) 120 (5.0 Ah) 55 (3.0 Ah) 70 (4.0 Ah) 90 (5.0 Ah)
Weight kg 0.4 0.5
An estimation of the level of exposure to
vibration should also take into account
the times when the tool is switched off or
when it is running but not actually doing
the job. This may significantly reduce
the exposure level over the total working
period.
Identify additional safety measures to
protect the operator from the effects of
vibration such as: maintain the tool and
the accessories, keep the hands warm,
organisation of work patterns.
english
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the
risk of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of electric
shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off position before
NOTICE: Indicates a practice not
related to personal injury which, if
not avoided, may result in property
damage.
Denotes risk of electric shock.
Denotes risk of fire.
EC-Declaration of Conformity
MACHINERY DIRECTIVE
BRUSHLESS CORDLESS COMPACT DRILL DRIVER/
HAMMERDRILL
DCD791, DCD796
D
eWALT declares that these products described
under Technical Data are in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010,
EN60745-2-1:2010, EN60745-2-2:2010.
These products also comply with Directive
2004/108/EC (until 19.04.2016), 2014/30/EU (from
20.04.2016) and 2011/65/EU. For more information,
please contact D
eWALT at the following address or
refer to the back of the manual.
The undersigned is responsible for compilation of
the technical file and makes this declaration on
behalf of D
eWALT.
Markus Rompel
Director Engineering
DeWALT, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
29.06.2015
WARNING: To reduce the risk of injury,
read the instruction manual.
General Power Tool Safety Warnings
WARNING! Read all safety warnings
and all instructions. Failure to follow
the warnings and instructions may result
in electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
