english
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough product development and innovation make
DeWALT one of the most reliable partners for professional power tool users.
Technical Data
DCD791 DCD796
Voltage V
DC
18 18
Type 1/10 1/10
Battery type Li-Ion Li-Ion
Power output W 460 460
No-load speed
1st gear min
-1
0–550 0–550
2nd gear min
-1
0–2000 0–2000
Impact rate
1st gear min
-1
— 0–9,350
2nd gear min
-1
— 0–34,000
Max. torque (hard/soft) Nm 70/27 70/27
Chuck capacity mm 1.5–13.0 1.5–13.0
Maximum drilling capacity
Wood mm 40 40
Metal mm 13 13
Masonry mm — 13
Weight (without battery pack) kg 1.1 1.2
BRUSHLESS CORDLESS COMPACT 13 mm (1/2")
DRILL/DRIVER, DCD791
BRUSHLESS CORDLESS COMPACT 13 mm (1/2")
DRILL/DRIVER/HAMMERDRILL, DCD796
Noise values and vibration values (triax vector sum) according to EN60745-2-1:
L
PA
(emission sound pressure level)
dB(A) 76 89
L
WA
(sound power level)
dB(A) 87 100
K (uncertainty for the given sound level)
dB(A) 3 3
Drilling into metal
Vibration emission value a
h
= m/s
2
<2.5 <2.5
Uncertainty K = m/s
2
1.5 1.5
Drilling into concrete
Vibration emission value a
h
= m/s
2
— 11.5
Uncertainty K = m/s
2
— 1.6
Screwdriving
Vibration emission value a
h
= m/s
2
<2.5 <2.5
Uncertainty K = m/s
2
1.5 1.5
English (original instructions)
3
