Lubrication
Your power tool requires no additionallubrication.
Blade Maintenance (Fig.H)
WARNING:
Use gloves and proper eye protection while
removing, sharpening, and installingblade.
The cutting blades are made from high quality, hardened steel
and with normal usage, they will not require resharpening.
However, if you accidentally hit a wire fence, stones, glass, or
other hard objects, you may put a nick in the blade. There is no
need to remove this nick as long as it does not interfere with the
movement of the blade. If you drop the trimmer, carefully inspect
it for damage. If the blade is bent, housing cracked, handles
broken or if you see any other condition that may affect the tool's
operation contact your local authorized service center for repairs
before putting it back intouse.
1. Remove thebattery.
2. Remove blade from pruner. See instructions for Removing
and InstallingBlade.
3. Wear proper eye protection and gloves and be careful not
to cutyourself.
4. Secure blade
6
in a vise
11
as shown in Fig.H.
5. Carefully file the cutting edge
12
of the cutting blade with
a fine tooth file
13
(not included) or sharpening stone (not
included), maintaining the angle of the original cuttingedge
of the cuttingblade.
6. Inspect the edge of the fixed blade and remove any burrs
with a fine toothfile.
7. Install sharpened cutting blade as described in the
Removing and InstallingBladesection.
Blade Lubrication (Fig.A)
1. After use, remove thebattery
8
.
2. Carefully apply a resin solvent to the exposedblades.
Storage (Fig.A)
WARNING: Keep your hands away from the blade.
1. After use, remove thebattery.
2. Store in a dry location, away from the reach ofchildren.
8. Install the new cuttingblade.
NOTE: Ensure the cutting edge faces toward the fixed
cutting blade as shown in Fig.F.
9. Insert the cutting blade screw
12
through the cutting
blade and screw mount
14
into nut
13
.
10. Use the hex wrench to loosely tighten the cutting blade
screw
12
.
11. Flip the product onto its other side and use the hex
wrench
10
to fully tighten the fixed blade screw
11
as
shown in Fig.G.
12. Flip the product onto its other side and use the hex
wrench
10
to fully tighten the cutting blade screw
12
.
Removing and Installing Blade (Fig. A, F, G)
DANGER: RISK OF INJURY. WHEN REASSEMBLING THE
BLADE SYSTEM, ENSURE EACH PART IS REINSTALLED
CORRECTLY, AS DESCRIBED BELOW. IMPROPER ASSEMBLY
OF THE BLADE OR OTHER PARTS OF THE BLADE SYSTEM
CAN CAUSE SERIOUSINJURY.
DANGER: To reduce the risk of serious personal
injury, turn unit off, remove battery pack before
making any adjustments or removing/installing
attachments or accessories. An accidental start-up can
causeserious personalinjury.
WARNING: Use gloves and proper eye
protection. Be careful of the sharp edges on theblade.
Replacement blades are available from your nearest
authorised servicecentre.
This pruner requires replacement
blade
DWZPRB300.
1. Remove thebattery.
2. Wear proper eye protection and gloves and be careful not
to cutyourself.
3. Place the product on a smooth, levelsurface.
4. Using the supplied hex wrench
10
loosen the fixed blade
screw
11
one full turn as shown in Fig.F. This will allow for
easier removal and assembly of the cutting blade
6
.
5. Flip the product onto its otherside.
6. Using the hex wrench
10
remove the cutting blade
screw
12
and nut
13
as shown in Fig.G.
7. Remove the cutting blade
6
as shown in Fig.G.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
in Fig. F. Refer to Proper Hand Position for more information.
Never hold the tool by theblades.
1. Position the branch to be cut between the cutting
blade
6
and fixed blade
7
.
2. Push the lock-off button
2
down and squeeze the lock-off
switch
3
then squeeze the trigger switch
1
.
3. The cutting blade
6
will make a cut cycle and cut the
branchoff.
NOTE: Cut branches at an angle for a cleanercut.
4. Release the triggerswitch.
NOTE: If more branches need to be cut, at the same time,
the lock-off switch
3
can be held down and actuate the
trigger switch
1
as needed. Otherwise, repeat steps 1-4..
