DeWalt DCN701D1 User Manual

ENGLISH
14
TROUBLESHOOTING GUIDE
Many common problems can be solved easily by utilizing the chart below. For more serious or persistent problems,
contact a
DEWALT
service center or call 1-(800)-4-
DEWALT
.

WARNING: To reduce the risk of serious personal injury, ALWAYS disconnect battery pack from tool before
allrepairs.
SYMPTOM CAUSE FIX
Tool will not fire Dryfire lock out engaged, blocking wire
indicator from traveling fully.
Load more staples into magazine.
Battery is hot. Let the battery cool or replace it with a cool pack.
Tool is hot. Let the tool cool down before continuing use.
Bent contact trip. See authorized service center.
Terminals are dirty or damaged. See authorized service center.
Damaged internal electronics. See authorized service center.
Damaged trigger. See authorized service center.
Jammed staple/drive blade not returned
to home position.
Remove battery, clear jammed staple, reinsert battery pack, driver blade
will reset by using the tool normally (first cycle will not fire a staple).
Damaged driver. See authorized service center.
Jammed internal mechanism. See authorized service center.
Damaged internal electronics. See authorized service center.
Tool operates but does not drive
fasteners fully
Tool not firmly applied to workpiece. Apply adequate force to tool securing it tightly to workpiece. Refer to
Actuating the Tool.
Damaged or worn driver tip. See authorized service center.
Damaged actuation mechanism. See authorized service center.
Tool operates, but no fastener
is driven
Wrong size or staples. Use only the recommended staples. Refer to Staple Specifications.
Debris in nosepiece. Clean nose area and watch closely for small pieces of broken staples stuck
in the track.
Debris in magazine. Clean magazine.
Damaged pusher spring. Replace spring. See authorized service center.
Worn magazine. Replace magazine. See authorized service center.
Jammed staples Wrong size or staples. Use only the recommended staples. Refer to Staple Specifications.
Magazine not secured after previous jam
clear/inspection.
Make sure the magazine is latched properly.
Material and fastener length. If the unit continues to stall, see authorized service center.
Debris in nosepiece. Clean nose area and watch closely for small pieces of broken staples stuck
in the track.
Worn magazine. Replace magazine. See authorized service center.
Damaged pusher spring. Replace springs. See authorized service center.
Damaged or worn driver. Replace driver with kit.
Staples do not fit Confirm D
E
WALT staples are being used. Your stapler is only compatable with D
E
WALT staples.
