DeWalt DCS571 User Manual

14
ENGLISH
To Attach the Dust Bag(Fig.K)
1. While holding the saw, fit the dust bag collar
26
to the dust
extraction port
24
as shown in FigureK.
2. Turn the collar
26
clockwise to lock the dust bag
25
inplace.
To Empty the Dust Bag(Fig.K)
1. While holding the saw, turn the collar
26
counterclockwise
to unlock the dust bag
25
.
2. Remove dust bag from the saw and gently shake or tap the
dust bag toempty.
3. Reattach the dust bag back onto the dust extraction port
and lock into place by turning the dust bag collarclockwise.
You may notice that all the dust will not come free from the
bag.This will not affect sanding performance but will reduce
the saw’s dust collection efficiency.To restore your saw’s dust
collection efficiency, depress the spring inside the dust bag
when you are emptying it and tap it on the side of the trash can
or dustreceptacle.
Workpiece Support (Fig. L, M)

WARNING: To reduce the risk of serious personal injury,
support the work properly and hold the saw firmly to
prevent loss ofcontrol.
Figure L shows proper sawing position.Figure M shows an
unsafe condition.Hands should be kept away from cuttingarea.
To avoid kickback, ALWAYS support board or panel NEAR the
cut.DON’T support board or panel away from the cut .
ALWAYS DISCONNECT SAW BEFORE MAKING ANY
ADJUSTMENTS! Place the work with its “good” side—the one
on which appearance is most important—down.The saw cuts
upward, so any splintering will be on the work face that is up
when you sawit.
MAINTENANCE
Your DeWALT power tool has been designed to
operate over a long period of time with a minimum of
maintenance.Continuous satisfactory operation depends upon
proper tool care and regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Lubrication
Your power tool requires no additionallubrication.
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents.Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool.These
chemicals may weaken the materials used in these
parts.Use a cloth dampened only with water and mild
soap.Never let any liquid get inside the tool; never
immerse any part of the tool into aliquid.
Lower Guard
The lower guard should always rotate and close freely from
a fully open to fully closed position. Always check for correct
operation before cutting by fully opening the guard and letting
it close. If the guard closes slowly or not completely, it will need
cleaning or servicing. Do not use the saw until it functions
correctly. To clean the guard, use dry air or a soft brush to
remove all accumulated sawdust or debris from the path of
the guard and from around the guard spring. Should this not
correct the problem, it will need to be serviced by an authorized
servicecenter.
Optional Accessories

WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.To
reduce the risk of injury, only
DeWALT recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Protecting the Environment
Separate collection.Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials.Please recycle electrical products and batteries
according to local provisions.Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails
to produce sufficient power on jobs which were easily done
before.At the end of its technical life, discard it with due care for
our environment:
• Run the battery pack down completely, then remove it from
thetool.
• Li‑Ion cells are recyclable.Take them to your dealer or a
local recycling station.The collected battery packs will be
recycled or disposed ofproperly.
