DeWalt DCS572 Instructions

50
ENGLISH
Clamps
38
are available to secure the guide rail
36
to the
workpiece
37
(Fig.Q). Use of these clamps
38
ensure that the
guide rail
36
is securely attached to the workpiece
37
for safe
working. Once the guide rail is set to the cut line and securely
fixed to the workpiece, there is no movement duringcutting.
IMPORTANT: The height scale on the unit is set for using the
saw without a guide rail. When using the saw on the guide rail
the difference in height will be approximately 5.0mm.
Setting the Circular Saw To the Guide
Rail(Fig.A,R)
The clearance between the circular saw and the guide rail
(Fig.R,
36
) must be very small to achieve best cutting results.
The smaller this clearance the better the straight line finish will
be on theworkpiece.
The clearance can be set with the two rail adjusters
11
,
12
(Fig.A) for each channel in the base for 0° cutting
11
and for
1–45° bevel cutting
12
. The rail adjusters are precision cams
that allow for the reduction of clearance between the unit
and guide rail. Once these adjusters have been set, sideways
movement of the saw during cutting is kept to a minimum
while allowing a smooth cuttingaction.
NOTE: The adjusters are set to minimum clearance in the
factory and may need adjusting and setting before the unit is
used. Use the following instructions for setting the circular saw
to the guiderail.
REMEMBER: Set the rail adjusters on the saw to the guiderail.
1. Undo the screw inside the rail adjuster to allow for
adjustment between the saw and the guiderail.
2. Retract the lower guard and place the unit on the guide rail,
ensuring the blade is in the highestposition.
3. Rotate the adjuster until saw locks on guiderail.
IMPORTANT: Make sure the saw is securely attached to the
rail by trying to push the saw forward. Ensure there is no
movement of thesaw.
4. Rotate the adjuster back slightly until saw slides easily along
therail.
5. Hold the rail adjuster in position and tighten the
screwagain.
NOTE: ALWAYS adjust the system for use with otherrails.
The rail adjusters are now set up to minimise sideways deviation
when cutting with the saw on the guiderail.
Before using the saw, the anti-splinter guard
39
on the guide
rail will need tuning in. Refer to Tuning the Anti-SplinterGuard.
Tuning the Anti-Splinter Guard (Fig.R)
The guide rail
36
is equipped with an anti-splinter guard
39
that has to be tuned to the saw before the firstuse.
The anti-splinter guard
39
is situated on each edge of the guide
rail. The purpose of this anti-splinter guard is to provide the user
with a visible blade cut line while reducing the chipping that
occurs along the workpiece cut edge duringcutting.
IMPORTANT: ALWAYS read and follow the Setting the
Circular Saw to the Guide Rail before cutting the splinter
guard!
Steps to Tune the Anti-Splinter Guard (Fig.S–V)
1. Place the guide rail
36
on a scrap piece of wood
40
with
a minimum length of 100mm overhanging the workpiece
(Fig. S). Use a clamp to ensure that the guide rail is securely
attached to the workpiece. This will ensureaccuracy.
2. Set the unit to a 20mm depth ofcut.
3. Place the front of the saw on the overhang end of the guide
rail, making sure that the blade is positioned in front of the
rail edge (Fig.T).
4. Turn the saw on and slowly cut the splinter guard along the
full length of the rail in one continuous operation. The edge
of the splinter guard now corresponds exactly to the cutting
edge of the blade (Fig.U).
To tune in the anti-splinter guard on the other side of the guide
rail, remove the saw from the rail and rotate the rail 180°. Repeat
steps 1 through4.
NOTE: If desired, the splinter guard can be bevelled to 45°,
then repeat steps 1 through 4. This allows one side of the rail for
cutting parallel cuts and the other side of the rail is tuned in for
45° bevel cuts (Fig.V).
NOTE: If the anti-splinter guard is tuned in for parallel cutting
on both sides, then when the unit is bevelled, the blade will not
run true to the edge of the anti-splinter guard. This is because
the pivot point of the unit bevel is not stationary and the blade
moves out over when the unit isbevelled.
Prior to Operation
• Make sure the guards have been mounted correctly. The saw
blade guard must be in closedposition.
• Make sure the saw blade rotates in the direction of the arrow
on theblade.
• Do not use excessively worn sawblades.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Proper Hand Position (Fig. J)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the main handle
30
,
with the other hand on the auxiliary handle
14
.
LED Worklight (Fig.A)
The LED worklight
10
is activated when the trigger switch is
depressed. When the trigger is released, the worklight will stay
illuminated for up to 20seconds.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as aflashlight.
