DeWalt DCV584L User Manual

11
ENGLISH
Fuel Gauge Battery Packs (Fig. C)
Some
DeWALT
battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
14
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Connecting the Hose (Fig. D)
Vacuum Mode
1. Insert the notched connecting piece
15
into the vacuum
inlet
4
.
2. Turn the connecting piece clockwise to fix the hose
intoposition.
3. Connect the appropriate accessory to the hose nozzle
11
.
Blow Mode
1. Insert the notched connecting piece
15
into the blow
outlet
5
.
2. Turn the connecting piece clockwise to fix the hose
intoposition.
3. Connect the appropriate accessory to the hose nozzle
11
.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING : To reduce the risk of serious personal
injury, turn appliance off and disconnect appliance
from power source and remove battery pack before
making any adjustments or removing/installing
attachments or accessories. An accidental start-up can
causeinjury.
Switching On and Off (Fig. A)
To switch the appliance on, set the on/off switch
1
to positionI.
To switch the appliance off, set the on/off switch
1
to
positionO.
Power Source
This vacuum runs either on mains power or battery power.
The vacuum will switch between AC (mains) and DC (battery)
powerautomatically.
Mains Power
1. Fully unwind the mainscable.
2. Connect the plug to the mains outlet before turning the
applianceon.
• Always turn the vacuum off when work is finished and
beforeunplugging.
• Tidy the mains cable when the vacuum is not inuse.
Battery Power
1. Tidy the mainscable.
2. Insert a battery pack
13
.
3. Make sure the battery pack is properlyseated.
NOTE: The mains cable power source is only designed to power
the operation of the vacuum and will not charge an installed
batterypack.
Vacuuming (Fig. A, E, F)
1. Empty and clean the tank
3
beforeuse.
2. Connect the notched connecting piece
15
to the vacuum
inlet
4
.
3. Select the appropriateaccessory.
NOTE: We recommend not mixing wet and dry substances.
When switching substances, empty and clean the tankfirst.
Dust Collection (Fig. E)
In the vacuum mode, your D
e
WALT vacuum can function as a
dust collector for applications producing dust ordebris.
Your D
e
WALT vacuum is fitted with the D
e
WALT AirLock
connection system. This system allows for a fast, secure
connection between the suction hose
9
and a power tool. The
AirLock connector
11
connects directly to D
e
WALT compatible
tools or through the use of the included AirLock adapter
12
.
NOTE: When using an adapter ensure it is firmly attached to the
tool outlet before following the stepsbelow.
1. Ensure the collar on the AirLock connector is in the unlock
position. Align notches on collar and AirLock connector as
shown for unlock and lockpositions.
2. Push the AirLock connector onto the adapter
connectorpoint.
3. Rotate the collar to the lockedposition.
NOTE: The ball bearings inside collar lock into slot and
secure the connection.The power tool is now securely
connected to the dustextractor.
Wet/Dry Filter (Fig. F)

WARNING : Always operate the appliance with the
dust filter
16
inplace.

WARNING : Always use the appliance in upright
position. Do not tilt the appliance, in order to
prevent liquids collected in the tank from entering
the motorhousing.

WARNING: If foam or liquid escapes from the machine,
switch offimmediately.

CAUTION: Clean the water level limiting device regularly
and examine it for signs ofdamage.
Shut-off Feature
If by mistake the appliance is used without the dust filter in
place, a shut-off feature will be actuated when the liquid level
in the tank has reached its maximum. A float valve will block the
suction opening, after which the suction stops and the motor
speedincreases.
