5
E
Using the Tool
1.
Point the laser at the top of the tool (Figure
A
1
) toward the wall whose distance you
need to measure (Figure
E
1
).
2.
Click (Figure
A
3
) to turn the tool on
and display a laser dot on the wall (Figure
E
1
).
3.
When the bottom of the tool is positioned
at the correct distance from the wall, click
to take the measurement (Figure
E
2
).
4.
View the measurement on the display
window (Figure
D
3
).
Changing the Unit of Measure
Once the current measurement is taken, you
can change the unit of measure from decimal
ft (6.21 ft) to fractional ft (6'02"9/16), fractional
ft to meters (1.894 m), meters to inches (74
9/16 in), or inches to decimal ft.
To change the unit of measurement, press
and hold until you see the measurement
change (3 seconds).
NOTE: If you continue to hold after the
measurement changes, the tool will turn off.
Re-measuring
1.
When you need to take a new
measurement, point the laser toward the
wall whose distance you need to measure.
2.
Click .
• The previous measurement (Figure
D
3
) will be cleared from the display
window.
• will change to in the display
window (Figure
D
2
).
3.
When the bottom of the tool is positioned
at the correct distance from the wall, click
to take the measurement (Figure
E
2
).
Turning Off the Tool
The tool can be turned off in either of these
ways:
• After taking a measurement, press and hold
for 5 seconds (until the display window
clears).
• If you do not use the tool for 120 seconds, it
will automatically turn off. (After 60 seconds,
the laser (red dot) will turn off and then after
another 60 seconds the unit will turn off.)
Warranty
Go to www.DEWALT.com for the latest
warranty information.
