DeWalt DW055PL User Manual

6
E
Specications
Range 6.5in to 55ft (.165m to 16.75m)
Measuring Accuracy* Typically ± 1/4in (± 6mm)*
Resolution** 1/16in (1mm)**
Laser Class Class 2 (IEC/EN60825-1: 2014)
Laser Wavelength ≤ 1.0mW @ 620-690nm
Auto Power Switch-off After 120s
Battery Life Up to 1000 Measurements
or 30 days (if the tool is not used)
Dimension (H x D x W) 2.44 x .69 x 1.25in (62 x 17.5 x 32mm)
Weight 1.12oz (31.75g)
IP Rating Water & Dust Resistant to IP54
Storage Temperature Range 19° F ~ 158° F (-7° C ~ +70 C)
Operating Temperature Range 32° F ~ 104° F (0° C ~ +40° C)
*Measuring Accuracy depends on the current conditions. Under favorable conditions (good
target surface, low background illumination, and good room temperature) up to 30ft (10m).
The measurement error can increase by up to ± 0.5mm/m for distances over 30ft (10m).
**Resolution is the nest measurement you can see. In inches, that is 1/16". In mm, that is
1mm.

DeWalt DW055PL Specifications

General

Quantity per pack	1 pc(s)
