ENGLISH
3
• Do not drive pins close to the edge of the work
piece as the wood may split, allowing the pin to
be deflected possibly causinginjury.
• This nailer produces SPARKS during operation.
NEVER use the nailer near flammable substances,
gases or vapors including lacquer, paint, benzine,
thinner, gasoline, adhesives, mastics, glues
or any other material that is ‑‑ or the vapors,
fumes or byproducts of which are ‑‑ flammable,
combustible or explosive. Using the nailer in any
such environment could cause an EXPLOSION
resulting in personal injury or death to user
andbystanders.

WARNING: When maintaining the tool:
• When working on air tools note the warnings in
this manual and use extra care when evaluating
problemtools.
Additional Safety Warnings
• Use the
DeWALT
pneumatic tool only for the purpose for
which it wasdesigned.
• Never use this tool in a manner that could cause a pin to
be directed toward the user or others in the workarea.
• Do not use the tool as ahammer.
• Always carry the tool by the handle with hand off both
triggers. Never carry the tool by the airhose.
• Do not alter or modify this tool from the original design or
function without approval from
DeWALT
.
• Always be aware that misuse and improper handling of
this tool can cause injury to yourself andothers.
• Never clamp or tape the trigger or secondary trigger in an
actuated position
• Never leave a tool unattended with the air hoseattached.
• Do not operate this tool if it does not contain a legible
WARNINGLABEL.
• Do not continue to use a tool that leaks air or does
not function properly. Notify your nearest
DeWALT
representative if your tool continues to experience
functionalproblems.
TO PREVENT ACCIDENTAL INJURIES:
• Never place a hand or any other part of the body in nail
discharge area of tool while the air supply isconnected.
• Never point the tool at anyoneelse.
• Never engage inhorseplay.
• Never actuate the tool unless nose is directed at thework.
• Always handle the tool withcare.
• Do not actuate the tool whileloading.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
COMPONENTS (FIG. A)

WARNING: Never modify the power tool or any part
of it. Damage or personal injury couldresult.
Refer to Figure A at the beginning of this manual for a
complete list ofcomponents.
Intended Use
Your pin nailer is designed for professional
fasteningapplications.
DO NOT use under wet conditions or in presence of
flammable liquids orgases.
Your pin nailer is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
TOOL SPECIFICATIONS
Model DWFP2350
Length 9.2" (234 mm)
Height 8.75" (222 mm)
Width 2.33" (60 mm)
Weight 2.50 lbs (1.1 kg)
Tool Air Fitting
This tool uses a 1/4" N.P.T. male fitting. The inside diameter
should be .200" (5mm) or larger. The fitting must be
capable of discharging tool air pressure when disconnected
from the airsupply.
Operating Pressure
70 to 100p.s.i.g. (4.8 to 6.9kg/cm²). Select the operating
pressure within this range for best pin performance. DONOT
EXCEED THIS RECOMMENDED OPERATINGPRESSURE.
Air Consumption
The DWFP2350 requires 2.05 cubic feet per minute (58liters
per minute) of free air to operate at the rate of 50pins per
minute, at 80p.s.i.g. (5.6kg/cm²). Take the actual rate at
which the tool will be run to determine the amount of air
required. For instance, if your pin usage averages 30pins per
minute, you need 50% of the tool’s c.f.m. of free air which is
required to operate the tool at 100pins perminute.
PIN SPECIFICATIONS
Model DWFP2350
Pins D
e
WALT DWPN23xxx
PORTER-CABLE PPN23xxx, PN23PP
BOSTITCH PT-23xx-3M, BTPN23PP
Gauge 23
Pin range 5/8"–2" (15.8–50.8 mm)
Magazine capacity 135 nails plus lock-out quantity
Adjustments and Usage Prep
Air Supply and Connections

WARNING: Do not use oxygen, combustible
gases, or bottled gases as a power source for this
tool as tool may explode, possibly causinginjury.
