33
ENGLISH
Do not incinerate the batterypack.
USE (without transport cap). Example: Wh rating
indicates 108Wh (1 battery with 108Wh).
TRANSPORT (with built-in transport cap). Example:
Wh rating indicates 3x 36Wh (3batteries of 36Wh).
Battery Type
These battery packs may be used: DCB181, DCB182, DCB183,
DCB183B, DCB183G, DCB184, DCB184B, DCB184G, DCB185,
DCB187, DCB189, DCBP034, DCBP034G, DCBP518, DCBP518G,
DCB546, DCB547, DCB547G, DCB548, DCB549. Refer to
Technical Data for moreinformation.
Package Contents
The package contains:
1 Universal dust extractor
1 Crevice tool
1 Suction cup
1 Carry strap
1 Belt hook
1 Stepped dust nozzle adaptor
1 Screw
1 Charger
1 Li-Ion battery pack (C1, D1, E1, G1, H1, L1, M1, P1, Q1, S1, T1,
U1, X1, Y1, Z1models).
2 Li-Ion battery packs (C2, D2, E2, G2, H2, L2, M2, P2, Q2, S2, T2,
U2, X2, Y2, Z2models).
3 Li-Ion battery packs (C3, D3, E3, G3, H3, L3, M3, P3, Q3, S3, T3,
U3, X3, Y3, Z3models).
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the dust extractor, parts or accessories
which may have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Dust Extractor
The following pictograms are shown on the dust extractor:
Read instruction manual beforeuse.
Date Code Position (Fig. I)
The production date code
17
consists of a 4-digit year followed
by a 2-digit week and is extended by a 2-digit factorycode.
Description (Fig. A, E, L)
WARNING: Never modify the dust extractor or any part of
it. Damage or personal injury couldresult.
1
Battery pack
2
Battery release button
3
Dust collection box
4
Dust collection box release
buttons
5
Filter cleaning mechanism
6
Dust extractor hose
7
Three position switch
8
Wireless Tool Control™
pairing button
9
LED
10
Carry strap
11
Carry strap hooks
12
Crevice tool
13
Suction Cup (Fig. E)
23
Wireless Tool Control™
remote (optional accessory
N547456)
25
DeWALT Bluetooth® Tool
Tag (optional accessory
DCE041)
Intended Use
Your DWH161 cordless dust extractor can be used for mobile
operation to take up dry, non-combustible dust. Only for
indooruse.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
DO NOT pick up materials that present a risk of explosion,
glowing or burning materials, flammable materials, gases or
other hazardoussubstances.
NOTE: This product is NOT to be used for filtering of pathogens,
for example Covid-19. Follow all local, state and federal
guidance on general cleaningpractices.
NOTE: This appliance is suited for professional and commercial
use, e.g. in hotels, schools, hospitals, factories, shops, offices,
rental companies, and on constructionsites.
• This machine is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience andknowledge.
• Children should be supervised to ensure that they do not
play with theappliance.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn the dust extractor off and disconnect
battery pack before making any adjustments or
removing/installing attachments or accessories. An
accidental start-up can causeinjury.
WARNING: Use only DeWALT battery packs andchargers.
Inserting and Removing the Battery Pack
from the Dust Extractor (Fig. B)
NOTE: Make sure your battery pack
1
is fullycharged.
To Install the Battery Pack into the Dust Extractor
1. Align the battery pack
1
with the rails inside the dust
extractor (Fig.B).
2. Slide the battery pack in until it is firmly seated in the dust
extractor and ensure that you hear the lock snap intoplace.
