DR4088CS / GND / OPTO 2021-08-11
P 10
www.digikeijs.com
® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
power supply
4.3 Feedback modules DR4088OPTO; Hall sensors, 3-wire track
Light barrier, Hall sensors or
the like
(posive switching PNP)
5V-20V
DC/AC
Feedback "Track mass"
switch track reed contact
DR4088OPTO
More DR4088xx
feedback unit
