Digikeijs DR 4088 series User Manual

DR4088CS / GND / OPTO 2021-08-11
P 12
www.digikeijs.com
® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
4.5 Feedback modules DR4088GND;switches, buons, reed contacts
push buon
switches
reed contacts
Feedback "Track mass" switch track reed contact
Track Out
Central
S88(N)®
Zentrale
Important! DR4088GND 3-wire operaon:
Due to the H-bridge (track output) in the DR50xx, feedback devices in the DR4088GND version must not be used against track ground, as
is usually the case with 3-wire tracks. This inevitably leads to the destrucon of the DR50xx.
If a 3-wire driver sll wants to drive with the DR50xx and report back against track ground, the DR4088OPTO
can be used.
DR4088GND
More DR4088xx
feedback unit
