Power| power supply | 9V Alkaline Dry Battery |
|---|---|
| power consumption | 4.8 Watts |
| optional power supply | PS200R - 100 (100V ~ 50/60Hz), 120 (120V ~ 60Hz), 230 (230V ~ 50Hz), 240 (240V ~ 50Hz) |
Electrical Specifications| input impedance | 1 MOhms |
|---|---|
| output impedance | 100 Ohms |
| battery life | Approximately 4 hours (with continuous usage) |
Weight and Dimensions| dimensions | 4 15/16” (L) x 3 1/8” (W) x 2 1/8” (H) |
|---|---|
| weight | 1.38 lbs |
Follow these 12 instructions for safe and proper operation of the device.
These knobs adjust trigger sensitivity and various effect parameters.
Connection point for the optional DigiTech PS200R power supply.
Instructions to enable cabinet simulation by holding the pedal and applying power.
