dji ACTION 2 User Manual

DJI Action 2 User Manual
©
2021 DJI OSMO All Rights Reserved.
10
Charging DJI Action 2
1. Connect a USB adapter (not included) to the USB-C port using the power cable (included).
2. The status LED on the front touchscreen module or the power module turns on during charging
when powered off. The battery is fully charged when the status LED displays solid green for six
seconds and turns o. It takes approximately 90 minutes to fully charge both the camera unit and
the front touchscreen module or the power module when they are connected.*
* Measured using a 5V/2A USB adapter in a laboratory environment. Use as a reference only.
Charge DJI Action 2 when the battery level is low. Storing the DJI Action 2 for more than four
months with low battery will reduce the battery life.
The camera unit will be charged first if the front touchscreen module or the power module is
connected to the camera unit during charging.
Usage
Power/Record Button
* Coming soon.
1. When powered o:
A. Press to power on.
B. Press and hold to quickly power on and begin shooting. The shooting mode will depend on the
SnapShot* settings.
2. When powered on:
A. Press to take photos or to start or stop recording. In settings or playback, press to return to
camera view.
B. Press and hold to enter sleep mode and press again to exit sleep mode. The camera will
automatically power o after 60 minutes in sleep mode. In QuickClip mode, press and hold to
extend recording time while recording.
C. Press twice to switch shooting mode.

dji ACTION 2 Specifications

General

Flip-out screen	-
Built-in display	Yes
Display diagonal	1.76 \
Display resolution	446 x 424 pixels
Product color	Gray
Waterproof up to	10 m
Protection features	Waterproof
Audio recording formats	AAC
Sensor type	CMOS
Total megapixels	12 MP
Optical sensor size	1/1.7 \
Image formats supported	JPEG, RAW
Maximum image resolution	4000 x 3000 pixels
Digital zoom	4 x
Fixed aperture	2.8 mm
Field of view (FOV) angle	155 °
ISO sensitivity	100, 6400
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Aspect ratio	4:3, 16:9
Video resolutions	1920 x 1080, 2688 x 1512, 3840 x 2160 pixels
Maximum frame rate	120 fps
Supported video modes	1080p
Video formats supported	H.264, HEVC, MP4
Maximum video resolution	4096 x 3072 pixels
Bitrate at maximum video resolution	130 Mbit/s
Storage media	Internal memory
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Battery voltage	3.85 V
Battery capacity	580 mAh
Battery life (max)	1.1 h
Operating temperature (T-T)	0 - 40 °C
Frequency band	2.400 - 5.850 GHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0

Weight and Dimensions

Depth	22.3 mm
Width	39 mm
Weight	56 g
