dji RC 2 User Manual

DJI RC 2
User Manual
12
©
2023 DJI All Rights Reserved.
Controlling the Aircraft
Three preprogrammed modes (Mode 1, Mode 2, and Mode 3) are available and custom modes
can be congured in the DJI Fly app.
Up
Down
Turn RightTurn Left
RightLeft
Forward
Backward
Left Stick Right Stick
Right Stick
Left Stick
Turn RightTurn Left
Up
Down
RightLeft
Forward
Backward
Right Stick
Up
Down
Forward
Backward
Left Stick
Turn RightTurn Left
RightLeft
Mode 1
Mode 2
Mode 3
The default control mode of the remote controller is Mode 2. In this manual, Mode 2 is used as
an example to illustrate how to use the control sticks.
• Stick Neutral/Center Point: control sticks are in the center.
• Moving the control stick: the control stick is pushed away from the center position.

dji RC 2 Specifications

General

Screen Size	5.5 inches
Resolution	1920 x 1080
Brightness	700 cd/m²
Video Output Port	HDMI
Wi-Fi Protocol	802.11 a/b/g/n/ac
Bluetooth Protocol	Bluetooth 5.2
Operating Temperature	-10° to 40° C
Weight	420 grams
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Charging Time	Approximately 2 hours
Supported DJI Aircraft	DJI Air 3
Battery	5200 mAh
Storage Temperature	-30° to 60° C (-22° to 140° F)
