Specications
OcuSync
Operating Frequency
[1]
2.4000-2.4835 GHz; 5.725-5.850 GHz
Max Transmission Distance
[2]
(unobstructed, free of interference)
15 km (FCC); 8 km (CE/SRRC/MIC)
Max Transmission Distance
[2]
(with interference)
Strong Interference (urban landscape, limited line of sight, many competing
signals): 1.5-3 km (FCC/CE/SRRC/MIC)
Medium Interference (suburban landscape, open line of sight, some
competing signals): 3-9 km (FCC); 3-6 km (CE/SRRC/MIC)
Weak Interference (open landscape abundant line of sight, few competing
signals): 9-15 km (FCC); 6-8 km (CE/SRRC/MIC)
Transmitter Power (EIRP)
2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC); <14 dBm (CE); <23 dBm (SRRC)
Wi-Fi
Protocol Wi-Fi 6
Operating Frequency
[1]
2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: <26 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5.1 GHz: <26 dBm (FCC); <23 dBm (CE/SRRC/MIC)
5.8 GHz: <26 dBm (FCC/SRRC); <14 dBm (CE)
Bluetooth
Protocol Bluetooth 5.1
Operating Frequency 2.4000-2.4835 GHz
Transmitter Power (EIRP) <10 dBm
General
Model RM700B
Screen
7.02-in LCD touchscreen, with a resolution of 1920×1200 pixels, and
high brightness of 1200 cd/m
2
Dimensions (antennas folded) 268×162.7×94.3 mm (L×W×H)
Weight
Approx. 1.25 kg (excl. WB37 battery)
Approx. 1.42 kg (incl. WB37 battery)
Internal Battery Li-ion (6500 mAh @ 7.2 V), Chemical System: LiNiCoAIO2
Charging Type
It is recommended to use USB-C chargers with maximum rated power
of 65W and maximum voltage of 20V
Rated Power 12.5 W
Storage Capacity 64GB + expandable storage via microSD card
Charging Time
2 hours (using a USB-C chargers with maximum rated power of 65W
and maximum voltage of 20V)
Operating Time
Internal Battery: Approx. 3 hours and 18 min; Internal Battery + External
Battery: Approx. 6 hours
Ingress Protection Rating IP54
GNSS GPS+Galileo+BeiDou
