5
CT THERMOSTAT PROGRAMMING AND OPERATION
A. Turning The CT Thermostat On And Off
1. Press the / Mode button to turn the CT thermostat on. See FIG. 1.
2. To turn the CT thermostat off, continue pressing the / Mode button until “Off” appears on
the LCD. After 15 seconds of illumination, the LCD turns off.
Dependent upon the systems installed, the Mode options you will scroll through are Off,
Fan, Cool, Furnace, Heat Pump, and Heat Strip.
B. Switching Between ºF and ºC
1. Simultaneously press the Up ( ) and Down ( ) buttons to toggle the LCD between °F and
°C. See FIG. 2.
FIG. 2
C. Displaying The Inside Temperature
1. Ensure the CT thermostat is in Off mode. If it is not, press the / Mode button until you
reach Off mode.
2. Press either the Up ( ) or Down ( ) button to display the temperature. See FIG. 3
FIG. 3
Inside
Temperature
