5
A. Table - Unit Data
Model No. Nominal
Capacity
(BTU HR)
Cooling
Electrical
Rating*
Compressor
Rated Load
Amps
Compressor
Locked
Rotor
Amps
Fan Motor
Rated Load
Amps
Fan Motor
Locked
Rotor
Amps
Refrigerant
R-410A
(oz)
Minimum
Wire Size**
AC Circuit
Protection
****Installer
Supplied
Minimum
Generator
Size***
1 Unit / 2 Units
Unit
Width
Unit
Height
Unit
Depth
Installed
Weight
(Pounds)
441003.701 10,150 120 Vac
60 Hz 1 ph
8.9 50.0 2.2 6.6 28.0 12 AWG
Copper
Up to 24'
20 Amp 2.8 kW / 40 kW 22″ 14.5″ 20.5″ 70
441003A701 10,150 8.9 50.0 2.2 6.6 28.0 20 Amp 2.8 kW / 4.0 kW 22″ 14.5″ 20.5″ 70
* Maximum unit performance achieved at full rated voltage.
** For wire length over 24 ft., consult the National Electrical Code for proper sizing.
*** Dometic Corporation gives GENERAL guidelines for generator requirements. These guidelines come from experiences
people have had in actual applications. When sizing the generator, the total power usage of your RV must be considered.
Keep in mind generators lose power at high altitudes and from lack of maintenance.
**** CIRCUIT PROTECTION: Time Delay Fuse or Circuit Breaker Required.
B. Interior Compartment/Sidewall Opening Requirements
1. A dedicated interior compartment MUST BE provided for the unit installation. This compartment MUST BE OPEN
TO THE OUTSIDE AND AIR SEALED TO THE INSIDE. Interior compartment must be at least 20″ deep with an
inside cabinet front cutout of 20″ x 14″. The opening must be 1″ above the mounting surface for the unit.
2. A 22-3/4″ wide x 15″ high opening through the sidewall or outside panel is required.
SPECIFICATIONS
