Technical description CT4000
20
5.1 Description of the components
5.2 Control and display elements
No. in
fig. 1, page 3
Label
1 Housing for cassette tank
2 Draining slider for toilet bowl
3 Toilet bowl, ceramic
4 Lid and seat, rotatable
5Console
6 Control and operating panel
7 Freshwater tank (optional)
8 CTLP, CTS, CTW only: Wall bracket
9 Cassette tank (capacity 19 l)
10 Service door (accessory)
11 CTW only: Tank flap (lockable tank flap optional)
No. in
fig. 2, page 3
Label
1 Flush button
2 “Cassette tank full” indicator
3 “Cassette tank 3/4 full” indicator
4 “Fill freshwater tank” indicator
(Not always connected when using the on-board tanks)
5 “Cassette tank removed” indicator
