CT4000 Maintenance
29
8.3 Replacing the cassette seal
➤ Release the slider from the cassette (chapter “Releasing the slider from the
cassette” on page 27).
➤ Push back the cover so that the seal is accessible (fig. g, page 10).
➤ Remove the support ring and the seal (fig. g, page 10).
A
➤ Insert the new seal (fig. i, page 11).
➤ Insert the support ring (fig. j, page 11).
➤ Grease all areas.
!
➤ Close the cover (fig. k, page 11).
➤ Place the slider back on.
8.4 Replacing the bayonet seal
➤ Release the slider from the cassette (chapter “Releasing the slider from the
cassette” on page 27).
➤ Remove the old seal (fig. l 2,page 12 ).
➤ Clean the bayonet fitting.
➤ Insert the new seal.
➤ Ensure uniform seating of the new seal.
➤ Place the slider back on.
➤ Grease all areas.
NOTICE!
The seal must be positioned uniformly in the opening (fig. h, page 10)
so that the cassette is sealed and the slider can move easily.
CAUTION! Danger of crushing!
Do not reach into the opening when you close the cover.
CT4000-O-18s.book Seite 29 Dienstag, 2. Mai 2017 7:15 19
