Installing the refrigerator RML9330 – RML9435
22
6.7 Securing the refrigerator
!
I
Proceed as follows (fig. h, page 7):
➤ Move the refrigerator into its final location.
➤ Fasten the four screws (1) through the four plastic washers in the sides of
the refrigerator, and further into the wall.
➤ Put the caps (2) onto the screw heads.
6.8 Reversing the door (RML9430/9431/9435 only)
➤ Remove the control panel.
– RML9430: Unscrew the dials carefully and loosen the screws, fig. i,
page 7
– RML9431/9435: Open the refrigerator door and undo the screws
underneath the control panel, fig. j, page 7
➤ Undo the hinge screw on the top door hinge and keep it in a safe place
(fig. k, page 8).
➤ Lift up the door and remove it (fig. l, page 8).
➤ Undo the two screws on the door lock and remove the door lock (fig. m,
page 8).
➤ Place the door lock on the other side again and tighten it with the two
screws (fig. n, page 8).
➤ Undo the hinge pin (fig. o, page 8) and position it on the other side
(fig. p, page 8).
➤ Turn the door by 180° (fig. q, page 8).
➤ Place the door on the hinge pin.
➤ Replace the control panel and screw it down tightly.
CAUTION!
Only drill through the receptacles provided, otherwise foamed
components, including cables, can be damaged.
NOTE
Attach the side walls or the attached strips so that the screws are
tight, even when under increased loads (while driving).
