Rollerblind Powered Operation
11
AP Remote control: fig. 5
Central control system: fig. 6
7.9 Connecting to an AP Remote control (optional)
I
➤ Refer to the AP Remote control manual for further instructions.
8Operation
!
3 Junction box (230 Vw only)
4 Single pole double throw centre off switch SPDT-CO (230 Vw only)
Item Description
1 Fused power supply
(fuse rating: 2 A for 12 Vg, 1 A for 24 Vg)
2 AP Receiver
Item Description
1 Fused power supply
(fuse rating: 2 A for 12 Vg, 1 A for 24 Vg, 1 A for 230 Vw)
2 Central control system (Single pole double throw centre off switch)
3 Central control system (AC motor controller)
4 Central control system communication bus
NOTE
The button for setting up the remote control is located as shown:
• BR leaflet: fig. f
• MP leaflet: fig. b
• CA leaflet: fig. b
CAUTION! Risk of injury
Only for boats and yachts: If the blind is in front of an open window,
then the blind should be stowed when driving at more than 10 knots or
in a sea state of more than moderate, as this can cause damage to the
blind. Parts that come loose may injure persons in the vicinity.
Item Description
RollerblindPowered_IOM_EMEA16.book Seite 11 Donnerstag, 21. November 2019 9:37 09
