Dräger Alcotest 5510 User Manual

6 Dräger Alcotest 5510
Description
2.2 Intended use
The Dräger Alcotest
®
5510
1
is used to quickly measure the alcohol
concentration in a person's breath. The device is suitable for portable
and battery-powered operation.
2.3 Device symbols and displays
The measured breath alcohol value is specified in the basic device
setting, in the unit of mg/L (= milligrams of ethanol per litre of breath).
The device can be converted to all common units of measurement at
the factory or by DrägerService.
2.3.1 Device symbols
Symbol for "See Instructions for Use".
2.3.2 Keys
OK key
C
onfirms entries or selected fu
nctions.
Key for switching the device on and off.
DOWN/Menu and UP key 
Setting values and selection of menu functions.
2.3.3 Battery symbol
Indicates the batteries' state of charge:
Batt
ery full
Battery 2/3 full
Battery 1/3 full
Battery empty
2.3.4
Menu
Return to the next menu level up
Menu item with submen
u
Open menu item
Available function
Further entries below the visible entries
Further entries above the visible entries
2.3.5 Function
Activated function
Current display (1) of the total display number (6)
1) Alcotest
®
is a registered trademark of Dräger.
i
OK
M
