Dräger Alcotest 7000 User Manual

Use |
Dräger Alcotest
®
7000 15
● Alcohol detected (see the fold-out page, Figure 2: H). The red
indicator also lights up. Press the button to continue with the
next measurement.
4.6.2 Taking a manual breath sample (optional)
If the subject cannot provide the required minimum volume of breath,
manual sampling can be activated.
To take a manual breath sample:
1. Follow steps one to four of the process for taking an automatic
breath sample.
2. Briefly press the button if the circular progress bar is displayed
once breath sampling has begun.
 In the results display, MANUAL is also displayed.
4.6.3 Taking a passive breath sample (optional)
During passive sampling, sampling is manually activated by the user
of the device. Possible applications for this include testing the ambient
air or a person's breath for the presence of alcohol.
To take a passive breath sample:
1. Hold the ready device without the mouthpiece in the air to be
analyzed.
2. Briefly press the button to start the measurement.
 If alcohol is detected, the message ALCOHOL is displayed
and the red LED lights up.
 If no alcohol is detected, the message NO ALC. is displayed
and the green LED lights up.
 In the results display, PASSIVE is also displayed.

Dräger Alcotest 7000 Specifications

General

Brand	Dräger
Model	Alcotest 7000
Category	Test Equipment
Language	English
