42
E
Checking brake pads for wear (fig. 30)
To facilitate inspection without removing the pads from
the calipers, brake pads have a wear mark. If the grooves
in the friction material are still visible, the pad is still in
good condition.
Important
Have the brake pads replaced at a Ducati Dealer or
Authorized Workshop.
;;
;;
;;
;;
;;
;;
;;
;;
;;
yy
yy
yy
yy
yy
yy
yy
yy
yy
MIN
fig. 30

Ducati 998S Specifications

General

Displacement	998 cc
Bore x Stroke	100 mm x 63.5 mm
Compression Ratio	11.4:1
Transmission	6-speed
Frame	Tubular steel trellis
Front Brakes	2 x 320 mm discs, 4-piston calipers
Tire Front	120/70 ZR17
Tire Rear	190/50 ZR17
Engine Type	Liquid-cooled, 4-stroke, L-twin, Desmodromic DOHC, 4 valves per cylinder
Torque	97 Nm @ 8000 rpm
Fuel System	Electronic fuel injection
Front Suspension	Showa 43mm upside-down fork, fully adjustable
Rear Suspension	Showa monoshock, fully adjustable
Rear Brakes	220 mm disc, 2-piston caliper
Fuel Capacity	17 liters
