Top Housing 7–1
Chapter 7 — Top Housing
D-Series Top Housing Removal
1. Loosen the candy cane compression nut and slide the candy cane away from the
check valve/anti-siphon.
2. Loosen and remove the four top housing bolts.
3. Spray the power cable and Equalizer tube with soapy water and lift off the top
housing from the top of the control compartment. Simultaneously slide the power
cable and Equalizer tube through the grommets.
4. Continue to the next section if the top housing will be replaced.
Figure 7-1
Figure 7-2
