Eaton 600 A 25 kV class PUSH-OP M Installation And Operation Instructions

11
SPEAR™ Single-Phase Recloser System
INSTALLATION AND OPERATION INSTRUCTIONS MN280048EN June 2016
Ratings and specifications
Check recloser ratings prior to installation
The recloser must be applied within its specified ratings.
Check data plate ratings and compare with the system
characteristics at the point of application prior to installation.
Tables 1–4 list the ratings and specifications for the SPEAR
single-phase recloser.
Table 1. Voltage and current ratings
Rating 15-8-400 15-12-630 15-12-800 27-8-400 27-12-630 27-12-800 38-8-400 38-12-630 38-12-800
Maximum Design Voltage (kV) 15.5 15.5 15.5 27.0 27.0 27.0 38.0 38.0 38.0
Nominal Operating Voltage (kV) 14.4 14.4 14.4 24.9 24.9 24.9 34.5 34.5 34.5
Basic Insulation Level (BIL*) (kV) 110 110 110 125 125 125 170 170 170
60 Hertz Withstand Voltage (kV)
Dry, one minute
Wet, ten seconds
50
45
50
45
50
45
60
50
60
50
60
50
70
60
70
60
70
60
Max RIV at 1.0 MHz
9.4 kV (μV)
16.4 kV (μV)
23.0 kV (μV)
100 100 100
100 100 100
100 100 100
Continuous Current Ratings (A) 400 630 800 400 630 800 400 630 800
Sym. Interrupting Current (A) 8,000 12,500 12,500 8,000 12,500 12,500 8,000 12,500 12,500
Overload Capability
125% – 8 Hours (A)
150% – 4 Hours (A)
500
600
788
945
None
–
500
600
788
945
None
–
500
600
788
945
None
–
Cable Charging Current (A) 10 10 10 25 25 25 40 40 40
Line Charging Current (A) 2 2 2 5 5 5 5 5 5
Three-Second Current, Sym. (A) 8,000 12,500 12,500 8,000 12,500 12,500 8,000 12,500 12,500
*Extended BIL option available on 15.5 kV and 27 kV products.
ote:N The SPEAR single-phase recloser incorporates a tank
heater which is configured for either 120 or 240 VAC.
Refer to the Tank and Heater Options section in
Catalog Data CA280001EN SPEAR™ single-phase
recloser system for additional information.
Table 2. Mechanical life
Minimum Operations 10,000
Table 3. Mass (weight) for SPEAR single-phase recloser
Recloser 15 kV 27 kV 38 kV
lbs (kg) 114 (52) 118 (54) 122 (56)
Table 4. Duty cycle
Percent of Maximum Circuit
Interrupting Rating
Minimum
X/R Ratio
Number of Unit
Operations at 12.5 kA
15-20 4 88
45-55 8 112
90-100 17 32
Total 232
