SPEAR™ Single-Phase Recloser System
INSTALLATION AND OPERATION INSTRUCTIONS MN280048EN June 2016
Removing recloser from service
WARNING
Hazardous voltage. Always use a hotstick when working
with this equipment. Failure to do so could result in
contact with high voltage, which will cause death or
severe personal injury.
G108.1
WARNING
Hazardous voltage. Do not rely on the open position
of the yellow operating handle on the recloser or the
OPEN or LOCKOUT LED indicators on the recloser
control; it does not ensure that the line has been
de-energized. Always establish a visible disconnect.
Failure to follow proper safety practices can result in
contact with high voltage, which will cause death or
severe personal injury.
G171.0
1. Close bypass switches.
2. Pull down the yellow operating handle with a hotstick.
The yellow operating handle is located under the
recloser sleet hood.
The control will sense that the recloser is open.
CAUTION
Equipment misoperation. Disconnect all control
power sources prior to disconnecting or reconnecting
the control cable from the control. Failure to comply
can result in recloser misoperation at the time of
disconnection or reconnection of the control cable to
the control.
T311.1
3. Open the source and load disconnect switches.
4. Remove the control AC sensing and power connections
from the control using a separate disconnect switch.
5. Disconnect the control battery.
IMPORTANT
Disconnect switches for AC sensing and power connections
are necessary to isolate the control for testing and
servicing.
CAUTION
Hazardous voltage. Open CT secondaries can generate
high voltages. Contact with CT pins of the disconnected
cable can cause electric shock and may result in
personal injury. Open recloser contacts and open
disconnect switches before disconnecting control
cable.
T204.3
CAUTION
Hazardous voltage. Cable conductors attached to
controls will remain at 53V DC and 120/240V AC
potential while connected to the control. Contact
with any pins at the end of the cable directly or
indirectly connected to a control can result in personal
injury or equipment damage. Disconnect battery and
external power sources in the control then remove
control cable at control end before disconnecting from
recloser end.
T312.3
6. Disconnect the control cable from the recloser.
7. Follow standard utility procedures regarding removal of
recloser from service.
ote:N Eaton recommends transporting SPEAR single-phase
reclosers in the closed position to maximize the
operational performance of the unit.
