Eaton 9E15Ki User Manual

Page 21
4.5 Alarm codes
Using a sophisticated self-diagnosis system, the UPS is able to check its own status and any anomalies and/or faults
which may occur during normal operation and display them on the display panel. If there is a problem, the UPS signals
the event by showing the code and the type of active alarm on the display.
ALARMS
“Minor” problems which reduce performance or prevent certain functions from being used.
CODE DESCRIPTION
A007
Fans blocked
A107
Cable connection error
A10A
Unbalanced input voltages (three-phase input)
A806
E.P.O control active
A80E
Overload: load > 105%
A810
Load percentage greater than the user threshold set
A60D
Batteries missing or Battery Box missing or not connected
A802
Low battery
FAULTS
Faults are normally preceded by an alarm signal and their scale leads to the power-off of the inverter and the load being
powered by the bypass line.
CODE DESCRIPTION
F002
UPS Fault
F004
Dissipator over temperature
F302 F303
Capacitor bank undervoltage
F300 F301
Capacitor bank overvoltage
F304
Unbalanced capacitor bank
F305
Failed capacitor bank soft start
F70D
Inverter overvoltage
F805
Short circuit
F704
Failed inverter soft start
F70C
Inverter undervoltage
F808
Output overload fault
F811
Negative output power
