Page 22
9PX 1-3 KVA US_EN
3. Installation
3.4 Connecting the EBM(s)
A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and
will not harm personnel. Insert the EBM cable into the UPS battery connector quickly and
1. Plug the EBM power cable(s) into the battery connector(s). Up to 4 EBMs may be connected
to the UPS.
2. Verify that the EBM connections are tight and that adequate bend radius and strain relief exist for
each cable.
3. Connect the battery detection cable(s) to the connector of the UPS and of the EBM(s).
3.5 Connecting other accessories
If you ordered other UPS accessories, refer to user manuals to check the connection
to the UPS.
9PXEBM48RT2U
9PXEBM72RT2U
