4
EATON IB528001EN Installation instructions
Installation Instructions - Arena Series
INSTALLATION
Step 1 – Mount The Luminaire
The first step is to attach the luminaire to the mounting structure. The mounting structure may be a light pole cross arm, an
indoor catwalk bracket, or other structural component that will hold the Luminaire in place. Refer to photometric drawings or
project Installation Drawings for luminaire installation locations and any additional mounting instructions.
WARNING
It is the responsibility of the installer to verify that all proposed mounting structures including poles, cross arms,
catwalk brackets, and other mounting structures are certified to support the weight of the luminaires, withstand
wind loads, and meet all other applicable codes and regulations. FAILURE TO FOLLOW THIS WARNING MAY LEAD TO
DEATH, SEVERE INJURY, OR PROPERTY DAMAGE.
WARNING
Do not suspend any luminaire by electrical or control wires, as these will not support the weight of the Luminaire,
resulting in the potential for the Luminaire to fall and cause damage or injury. FAILURE TO FOLLOW THIS WARNING
MAY LEAD TO DEATH, SEVERE INJURY, OR PROPERTY DAMAGE.
Equipment Required:
Mounting Hardware
Socket wrenches and/or crescent wrenches sized to fit mounting hardware
Cable ties or wire management restraints (For outdoor installations use UV rated material)
ote:N Before mounting luminaires, refer to the steps below to verify correct installation.
WARNING
Do not attempt to connect Arena Luminaires to any circuits with nominal voltage outside the below ranges for high
voltage and low voltage power supplies, respectively:
Between 120V AC and 277 V AC for low voltage power supplies.
Between 347V AC and 480V AC for high voltage power supplies
In other words, make sure the circuit voltage matches the power supply ratings defined in the table above. FAILURE
TO FOLLOW THIS WARNING MAY LEAD TO LUMINAIRE INTERNAL DAMAGE AND FAILURE.
Power Quality
The voltage on the lighting circuits must stay within 3% of nominal at 60Hz. Voltage that is consistently too high or low shall
be corrected before LED luminaires are installed.
If you require assistance in checking your power system or designing or implementing solutions, contact Eaton’s Electrical
Engineering Services and Systems. Find more information at www.eaton.com.
Arena 600 Current Draw
Voltage (Volts AC) Current (Amps)
120 5.3
208 3.3
240 2.8
277 2.3
347 2.0
480 1. 5
