8 Technical data
ESR5-NO-21-24VAC-DC 12/19 MN049007EN www.eaton.com 13
8 Technical data
Input data
Nominal input voltage U
N
24 V AC/DC
Input voltage range (factor) 0.85 - 1,1
Typical input current 140 mA AC
65 mA DC
Voltage at input/start and feedback circuit
∼ 24 V DC
Max. permissible overall conductor resistance
(Input and reset circuit at U
N
)
∼ 50 Ω (Input and start circuits at U
N
)
Typical response time
100 ms (automatic start)
Typical release time 45 ms (single-channel)
Recovery time 1 s
Operating voltage display
Green LED
Status display
Green LED
Protective circuit Surge protection Suppressor diode
Output data
Contact type 2 enabling current paths
1 signaling current path
Contact material
AgSnO
2
+ 0,2 μm Au
Minimum switching voltage 15 V AC/DC
Maximum switching voltage 250 V AC/DC
Limiting continuous current 6 A (N/O contact)
Maximum inrush current 6 A
Inrush current, minimum 25 mA
Sq. Total current
(I
TH
)
2
= (I
1
)
2
+ (I
2
)
2
+ (I
3
)
2
72 A
2
(see derating curve, ￫ Figure 3, page 9)
Interrupting rating (ohmic load) max.
144 W (24 V DC, τ = 0 ms)
288 W (48 V DC, τ = 0 ms)
77 W (110 V DC, τ = 0 ms)
88 W (220 V DC, τ = 0 ms)
1500 VA (250 V AC, τ = 0 ms)
Maximum interrupting rating (inductive load)
48 W (24 V DC, τ = 40 ms)
40 W (48 V DC, τ = 40 ms)
35 W (110 V DC, τ = 40 ms)
33 W (220 V DC, τ = 40 ms)
Switching capacity min.
0.4 W
Mechanical service life ∼ 10
7
cycles
Switching capacity (360 cycles/h) 6 A (24 V DC)
5 A (230 V AC)
Switching capacity (3600 cycles/h)
3 A (24 V (DC-13))
3 A (230 V (AC-15))
Output fuse
10 A gL/gG NEOZED (N/O contact)
6 A gL/gG NEOZED (N/C contact)
