33
Appendix
Torque Specifications
* Thread adhesive sealant required.
Part Torque
Flywheel capscrews Follow engine manufacturer’s specifications
Transmission-to-Engine capscrews
7/16-14 * 37 - 50 lbs. ft. [50 - 68 N•m]
3/8-16 * 25 - 32 lbs. ft. [34 - 43 N•m]
M10 x 1-3/8 * 26 - 35 lbs. ft. [35 - 47 N•m]
M10 x 1-3/4 * 26 - 35 lbs. ft. [35 - 47 N•m]
Output yoke nut 450 - 500 lbs. ft. [610 - 678 N•m]
PTO mounting capscrews:
6-bolt opening * 20 - 25 lbs. ft. [27 - 34 N•m]
8-bolt opening * 50 - 65 lbs. ft. [68 - 88 N•m]
Reverse switch (9/16-18) 20 - 25 lbs. ft. [27 - 34 N•m]
Neutral switch/cap (3/4-16) 20 - 25 lbs. ft. [27 - 34 N•m]
Speedometer electronic sensor (3/4-16) 10 - 15 lbs. ft. [14 - 20 N•m]
Lubricant fill plug (1¼-NPT) 60 - 75 lbs. ft. [81 - 101 N•m]
Lubricant drain plug (3/4-NPT) 45 - 55 lbs. ft. [61 - 75 N•m]
Lifting bracket capscrew (3/8-16) 35 - 45 lbs. ft. [47 - 61 N•m]
Rear bearing cover capscrew (3/8-16) 35 - 45 lbs. ft. [47 - 61 N•m]
Transmission nodal mount capscrews (3/4-10) 180 - 190 lbs. ft. [244 - 258 N•m]
Transmission rear support stud nuts (5/8-18) 170 - 185 lbs. ft. [230 - 250 N•m]
Range Air Valve Mounting Screw (#10-24) 21 - 27 lbs. in. [2 - 3 N•m]
