Installation Requirements
Installation
Requirements
Requirements
All Top 2 transmission systems installed at OEM facilities must meet the requirements for standard manual Eaton Fuller
Transmissions outlined in Form FUL-169 and be approved using the Eaton Automated Transmission Application
Approval Form FUL-170. Both forms can be found in the Appendix.
1. Air Dryer Requirements - A high quality commercially available vehicle air dryer is required to be used in conjunction
with Top 2 systems.
2. Clutch Requirements - Spring dampened clutches are required for all applications.
3. Electrical Requirements - All wires are to be a minimum of 16 gauge GXL.
4. Integral Coolers - Reference Form FUL-169 Note 2 for transmission cooler requirements.
5. Line Inspection - All Eaton Top 2 transmission systems installed at OEM plants must pass the requirements outlined in
the “Line Inspection Form” prior to shipment.
6. Lubrication Requirements - Transmission oil should meet specifications as outlined in TCMT-0020 (Roadranger Prod-
ucts Approved Lubricants) and TCMT-0021 (Roadranger Products Lubrication Manual).
7. Power Connections - All ECMs will have redundant power and ground pins. If no redundancy is available, a relay con-
nection similar to the one on page 29.
8. Valve Spatial Requirements - The Top 2 solenoid valve requires a minimum of 2” clearance from any high temperature
devices (i.e. exhaust crossover pipes).
