Chengdu Ebyte Electronic Technology Co,;Ltd E32-DTU (433NW20) user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 11
5.7. Transceiver Length and Sub-packing Mode
Model
Buffer
Sub-package
E64-DTU (433NW20)
512Byte
Automatically send 55 bytes per package
★ Note:
1. If the data received by the station in a single time is larger than the capacity of a single packet, the excess data
will be automatically allocated to the second transmission until the completion of transmission.
2. The data transceiver cannot receive data which is more than the buffer capacity;
6. Operating mode
E64-DTU (433NW20) has four operating modes, if low power consumption is not required, normal communication is
recommended to configure the data transceiver for the normal mode (mode 0);
The factory default is normal mode (mode 0).
Categories
M1
M0
Description
Mode 0
Master Mode
ON
ON
Listen for all numbered slave data in the same channel. If the slave
WOR is turned on, the slave can be awakened
Mode 1
Slave sending Mode
ON
OFF
The module sends the data to the Master
Mode 2
Slave receiving Mode
OFF
ON
Open WOR to wait for host data
Mode 3
Sleep Mode
OFF
OFF
Parameter setting using the configuration software
★ Note: no need to care about the wake-up mode (mode 1) and power saving mode (mode 2) if it doesn’t reques t low
power consumption.
