Ebyte E77-M22S Series User Manual

Chengdu Ebyte Electronic Technology Co., Ltd. E77-xxxM22S User Manual
Copyright © 2012-2 024 , Chengdu Ebyte Electronic Technology Co., Ltd.
33
9 Data Rates of Each Frequency Band
EU433/EU868/RU864/AS923 :
data rate
Configuration
Represents physical data rate [bit/s]
0
LoRa: SF12 / 125 kHz
250
1
LoRa: SF11 / 125 kHz
440
2
LoRa: SF10 / 125 kHz
980
3
LoRa: SF9 / 125 kHz
1760
4
LoRa: SF8 / 125 kHz
3125
5
LoRa: SF7 / 125 kHz
5470
6
LoRa: SF7 / 250 kHz
11000
7
FSK: 50kbps
50000
8~15
RFU
CN470/KR920 :
data rate
Configuration
Represents physical data rate [bit/s]
0
LoRa: SF12 / 125 kHz
250
1
LoRa: SF11 / 125 kHz
440
2
LoRa: SF10 / 125 kHz
980
3
LoRa: SF9 / 125 kHz
1760
4
LoRa: SF8 / 125 kHz
3125
5
LoRa: SF7 / 125 kHz
5470
6 ~ 15
RFU
data rate
Configuration
Represents physical data rate [bit/s]
0
LoRa: SF10 / 125 kHz
980
1
LoRa: SF9 / 125 kHz
1760
2
LoRa: SF8 / 125 kHz
3125
3
LoRa: SF7 / 125 kHz
5470
4
LoRa: SF8 / 500 kHz
12500
5~7
RFU
8
LoRa: SF12 / 500 kHz
980
9
LoRa: SF11 / 500 kHz
1760
10
LoRa: SF10 / 500 kHz
3900
11
LoRa: SF9 / 500 kHz
7000
12
LoRa: SF8 / 500 kHz
12500
13
LoRa: SF7 / 500 kHz
21900
14 ~ 15
RFU
