Echo SHC-261 User Manual

SHAFT HEDGE CLIPPER
OPERATOR'S MANUAL
13
SPECIFICATIONS
MODEL SHC-261
Length 2230 mm (87.8 in.)
Width 250 mm (9.84 in.)
Height 250 mm (9.84 in.)
Weight (dry) 6.0 kg (13.2 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore
34.0 mm (1.34 in.)
Stroke
28.0 mm (1.10 in.)
Displacement
25.4 cc (1.55 cu. in.)
Exhaust Spark Arrestor Muffler w/Catalyst
Carburetor Walbro diaphragm model WYJ w/primer pump
Ignition System Flywheel magneto, capacitor discharge
Spark Plug
NGK BPM-7Y (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio 50:1 ECHO High Performance, two-stroke air cooled engine oil
Gasoline
89 Octane unleaded. DO NOT use fuel containing methyl alcohol, more than
10% ethyl alcohol or 15% MTBE.
Oil 50:1 ECHO High Performance, two-stroke air cooled engine oil
Fuel Tank Capacity
0.58 lit. (19.6 US fl. oz.)
Recoil Starter System Automatic Recoil Starter
Clutch Centrifugal Type
Gear Case Ratio 6.36:1 Reduction
Cutter
Length
Pitch
Double Reciprocating Blade - Double Edge
575 mm (22.6 in.)
35 mm (1.4 in.)
Idle Speed 2800 - 3200 RPM
Wide Open Throttle Speed (W.O.T.) 8000 - 10000 RPM
