SRM-3020 MAINTENANCE
X7502350002 33
© 2/20 ECHO Incorporated
• Lightly brush debris from filter. Replace filter if it is damaged, fuel
soaked, very dirty, or the rubber sealing edges are deformed.
5. Assemble components in reverse order.
Assure air filter is assembled
with pleats oriented vertically.
Fuel Filter
Level 1.
Parts Required: Tune Up Kit.
Fuel is VERY flammable. Use extreme care when mixing, storing
or handling, or serious personal injury may result.
1. Use a clean rag to remove
loose dirt from around fuel cap
and empty fuel tank.
2. Pull fuel filter out through gas
port, and inspect fuel filter.
3. When the fuel filter is dirty,
replace it as follows:
a. Do not remove the wire coil
clamp to remove the fuel
filter. Pinch the fuel filter
with the fingers on one
hand and the fuel line with
the other hand. Pull and
twist slightly to separate.
