ECS 915P-A User Manual

32
Using BIOS
OnBoard Floppy Controller (Enabled)
Use this item to enable or disable the onboard floppy disk drive interface.
Serial Port1 Address (3F8/IRQ4)
Use this item to enable or disable the onboard COM1 serial port, and to assign a port address.
Parallel Port Address (378)
Use this item to enable or disable the onboard Parallel port, and to assign a port address.
Parallel Port Mode (ECP)
Use this item to select the parallel port mode. You can select Normal (Standard Parallel
Port), ECP (Extended Capabilities Port), EPP (Enhanced Parallel Port), or BPP (Bi-
Directional Parallel Port).
Parallel Port IRQ (IRQ7)
Use this item to assign IRQ to the parallel port.
OnBoard PCI IDE Controller (Both)
Use this item to enable or disable either or both of the onboard Primary and Secondary IDE
channels.
Features Setup
This page sets up some parameters for peripheral devices connected to the system.
OnBoard Floppy Controller Enabled
Serial Port1 Address 3F8/IRQ4
Onboard IR Port Disabled
Parallel Port Address 378
Parallel Port Mode ECP
ECP Mode DMA Channel DMA3
Parallel Port IRQ IRQ7
OnBoard PCI IDE Controller Both
ATA/IDE Configuration Enhanced
Ethernet Device Enabled
Audio Device Enabled
Onboard USB Function Enabled
USB Function For DOS Disabled
Allow BIOS to Enable or
Disable Floppy Controller.
Help Menu
CMOS Setup Utility - Copyright (C) 1985-2004, American Megatrends, Inc.
Features Setup
: Move
F10: Save
F1: General help
+/-/: Value
Enter : Select
ESC: Exit
F9: Optimized Defaults
F8:Best Performance Settings
ECP Mode DMA Channel (DMA3)
Use this item to assign the DMA Channel under ECP Mode function.
Onboard IR Port (Disabled)
Use this item to enable or disable the onboard IR port function.
